ePulse Cloud Data Storage and Telemetry Analysis
EP2100 Full Automation Disinfection System Brochure
EP2100 - Advanced Wash Water Sanitizer Control
Reliable, Flexible, Powerful
The EP2100 Advanced Water Disinfection Automation System provides reliable, flexible and powerful control for your water treatment program.
- Controls up to 6 complex functions
- Touch screen display with icon-based programming makes setup easy
- Analytical sensors measuring pH, ORP, conductivity, disinfection, fluorescence and flow meter input
- Lifetime Cloud Data Storage and Telemetry Analysis, perfect for easily passing audits
The Advanced EP2100N is an essential “state of the art” tool for complete
automation and management of the water treatment process. It
provides multi parameter monitoring, pump and valve control, data
recording and data reporting of all the processes. The EP2100 uses real
time monitoring with internet and network connectivity using Ethernet or
WiFi. The EP2100 measures Chlorine, Chlorine Dioxide, Peroxy Acetic
Acid (PAA), pH, ORP or Conductivity. Modular design allows you to
select any desired measurement options.
EP2100 has up to 8 sensor inputs, 24 Analog Inputs (4-20mA), 12 digital inputs, 16 analog outputs and 12 relay outputs. It includes Data Recording and ePulse Data Management. With analog input signals of 4-20 mA, a variety of measurements may be used such as ppm of active free chlorine (AFC), ppm of chlorine dioxide, chemical level for inventory management and flow rate and totalizing for monitoring water usage, etc. Digital input channels may be used for discrete inputs such as flow sensors, flow switches, and process interlocks.
Features
- Works with Chlorine, Chlorine Dioxide, Peroxy Acetic Acid, pH, ORP or Conductivity.
- Ethernet or WiFi internet or network connectivity
- Multi Parameter Monitoring
- Real Time Monitor
- Built-in Safety Alarms
- Unique Algorithms
Key Benefits:
- Email, alarm messages, datalog, graph, or system summary reports
• Datalogging
• Ethernet or WiFi for remote access via the Internet, LAN,or optional BACnet or Modbus/TCP
• Large, full-color touchscreen display with icon based programming makes setup easy
• Universal sensor input provides extraordinary flexibility; the same controller can be used with
almost any type of sensor needed
• Four I/O slots allow complete flexibility in adding sensors, analog outputs and Linear Polarization
Resistance (LPR) corrosion sensors
• Multiple language support allows simple setup
• Three to twelve relay control outputs allow the controller to be used in more applications
• Sixteen virtual inputs and sixteen virtual outputs
• Economical wall-mount package for easy installation
• On-screen and web page graphing of sensor values and control output status
• Complete flexibility in the function of each relay
