Product Description
| Mechanical Flowmeter with Acrylic in-line Body |
| BlueWhite F-420N Mechanical Flowmeter with 316 SS guide rods |
Features
- Tough machined acrylic meter body, highly polished to a clear finish
- Direct reading permanent scale
- White back reflector for easy reading
- F/NPT adapters with high grade Viton o-ring seals and aluminum “stress ring” thread supports
- 316 stainless steel or Hastelloy rod guided floats
- Acceptable in direct sunlight applications
Specification:
Max. Working Pressure: 130 psig (8.9 bar) at 70°F (21°C)
Max. Fluid Temperature: 130°F (54°C) @ 0 PSI
Full Scale Accuracy: ±5%
Meter Body Material: Machined Acrylic
O-ring Seals: Viton (optional EP)
Approx. Shipping Wt.: 2 lb. (.91kg)
Models
|
Model Number
|
GPM
|
Adapter Size
|
Adapter Material
|
Float Material
|
Guiderod Material
|
|
F-42025LN-16
|
5 to 25
|
1" F/NPT
|
PVC
|
316 SS
|
316 SS
|
|
F-42025LN
|
5 to 25
|
1-1/2" M/NPT
|
PVC
|
316 SS
|
316 SS
|
|
F-42040LN-16
|
8 to 40
|
1" F/NPT
|
PVC
|
316 SS
|
316 SS
|
|
F-42040LN
|
8 to 40
|
1-1/2" M/NPT
|
PVC
|
316 SS
|
316 SS
|
|
F-42050LN-16
|
10 to 50
|
1" F/NPT
|
PVC
|
316 SS
|
316 SS
|
|
F-42050LN
|
10 to 50
|
1-1/2" M/NPT
|
PVC
|
316 SS
|
316 SS
|
